Lift off hinges P10064
Manufacturer - Argenta (Belgium)

    • rounded shape
    • with fixed stainless steel axle and ring
    • height: 100 mm
    • roll diameter: 16 mm, axle diameter: 10 mm
    • material thickness: 3 mm
    • please indicate door swing direction upon order
    • material: stainless steel


All prices include VAT
  • Products
  • Price
  • In Stock
  • Quantity
  1. Rebated hinge 100x64, st.steel, left
    Rebated hinge 100x64, st.steel, left
    Code: SB00016715
    Art. Nr.: 855 P10064 NT KR
    From €17.45
    In Stock: 57 pc.
  2. Rebated hinge 100x64, st.steel, right
    Rebated hinge 100x64, st.steel, right
    Code: SB00016716
    Art. Nr.: 855 P10064 NT LA
    From €17.45
    In Stock: 56 pc.
adjustment not adjustable
anti-corrosion resistance class 3 according to EN 1935 - high
anti-corrosion resistance in accordance with EN 1935 class 3 - high
anti-intruder protection no
base assortment Yes
class as per EN 1935 class 3
corner radius R10
door construction for rebated doors
door direction when ordering please indicate door swing direction
fastening elements must be ordered separately
fire safety suitable for fire and smoke safety doors
groove for leaf seal no
height 100 mm
hinge shape rounded
hinge type standard hinge
installation template available for sale or rent
knuckle diameter 16 mm
leaf maximum weight 80 kg
leaf material wood
load capacity middle
maintenance not required (self-lubricating bearings)
Manufacturer ARLU
material stainless steel
material thickness 3 mm
sound insulation no
spindle diameter 10 mm
suitable for aluminium frames suitable
suitable for industrial frames suitable
suitable for steel frames suitable
suitable for timber frames suitable
Durvju vērtņu virzieni saskaņā ar DIN 107
Vērtnes virzienu nosaka tajā durvju pusē, kur aizvērtā stāvoklī ir redzamas eņģes: redzamas eņģes vērtnes labajā pusē = DIN labā vērtne redzamas eņģes vērtnes kreisajā pusē = DIN kreisā vērtne
