Set of strike plates for multi-point locks with hooks and bolts 15-530E/3615-530Q31
Product code
USB25-351ERH-3625-351Q
Central strike plate KFV 15-530E
Manufacturer - KFV (Germany)
Auxiliary casing strike plate KFV 3615-530Q
Manufacturer - KFV (Germany)
Adjustment module Q (standard set)
Manufacturer - KFV (Germany)
-
- angled security strike plate for multi-point lock base body
- adjustable latch seat
- size: 250 x 10 x 30 mm
- thickness: 3 mm
- rounded face plate, R: 8 mm
- standard strike plate is fitted with adjustable latch seat KFV 115-34 which may be changed to electromagnetic door release or rolling latch lock KFV 115B
- please indicate door swing direction (left/right) upon order
- finish: light galvanised
Auxiliary casing strike plate KFV 3615-530Q
Manufacturer - KFV (Germany)
-
- angled security strike plate for wooden doors
- suitable for multi-point lock auxiliary locks with hook and bolt
- size: 180 x 10 x 30 mm
- thickness: 3 mm
- rounded face plate, R: 8 mm
- adjustable depth
- please indicate door swing direction (left/right) upon order
- available finishes: light galvanised
Adjustment module Q (standard set)
- saves installation time and costs
- increased adjustment range to 5 mm (+/ 2,5 mm)
- higher thermal insulation and protection against wind and rain
- sturdy fixation with 3 screws delays warping under extreme bolt or hook side-pressure
- elegant design in grey tones
- fits locks with a hook depth of 8 mm
All prices include VAT
- Products
- Price
- In Stock
- Quantity
-
USB 25-351ERH/31L-M-SKG 2 pretplāksne, 8x30x245 mm, KREISĀCode: SB00023769Art. Nr.: 3493239Price:From €19.93In Stock: 1 pc. -
USB 25-351ERH/31R-M-SKG 2 pretplāksne, 8x30x245 mm, LABĀCode: SB00023770Art. Nr.: 3493238Price:From €19.93In Stock: 3 pc.
-
USB 3625-351Q/31L--SKG 2 pretplāksne daudzpunktu slēdzeņu papildkorpusiem, 8x30x180 mm, KREISĀCode: SB00023771Art. Nr.: 3493247Price:From €18.09In Stock: 2 pc.
-
USB 3625-351Q/31L--SKG 2 pretplāksne daudzpunktu slēdzeņu papildkorpusiem, 8x30x180 mm, LABĀCode: SB00023772Art. Nr.: 3493246Price:From €18.09In Stock: 6 pc.
| width | 30 mm |
|---|---|
| case material | wood |
| door construction | for non-rebated and rebated doors |
| door direction | when ordering please indicate door swing direction |
| installation type | flush |
| lock type (lock points) | multi-point |
| Manufacturer | KFV |
| material | steel / stainless steel |
| product type | Strike plate set for multi-point locks |
| purpose | for exterior doors |
| shape | rounded |
| strike plate compatibility | for round bolts + hooks |
