Door closer GEZE TS 2000 NV BC with Hold-Open link arm
Product code
TS2000-NVBC-HO
To purchase a door closer please select the required arrangement below in the section ‘Description’.
Mounting accessories and auxiliary tools are listed in the section 'Additional products' of our E-shop.
Mounting accessories and auxiliary tools are listed in the section 'Additional products' of our E-shop.
Door closer GEZE TS 2000 NV BC with Hold-Open link arm
Manufacturer - GEZE (Germany)
- top-mounted door closer body with hold-open link arm
- integrated back check that cannot be deactivated
- suitable for interior and exterior doors with single leaf
- door leaf width up to 1100 mm
- installation door push side / pull side
- suitable for both left and right hand doors opening either inwards or outwards
- functions can be set from front (force adjustment from side)
- adjustable closing speed
- integrated back check slows the closer down in a set angle - it becomes more difficult to open in order to prevent the door from swinging open at too wide an angle
- back check activates at ~80° opening angle, the angle is not adjustable
- hydraulic latching action, adjustable via valve
- closing force can be adjusted via valve, fitting to sizes 2-4 according to EN 1154
- max opening angle: 180º
- mechanical hold-open arm with on/off switch
- adjustable hold-open angle: 70º - 150º
- not suitable for fire-protection doors
- closer body size: 226 x 48 x 60 mm
- colours: silver, black RAL9005, white RAL9016, dark brown
Arrangements and prices (Please select!)
| application | for hinged doors |
|---|---|
| back check | hydraulically adjustable |
| closer operating type | hydraulic closer |
| closer type | with a link arm |
| closing force adjustment position | from the side |
| closing force adjustment | continuous control with valve |
| doorstop | no |
| fire safety | not suitable for fire safety doors |
| hold open | yes, with fixing arm |
| installation type | to be screwed on door leaf/frame |
| latching action | adjustable with valve |
| link arm type | Hold-Open WITH on/off switch |
| maximum single leaf width | up to 1100 mm |
| Maksimālais vēršanas spēks pēc EN 1154 | 4 |
| Manufacturer | GEZE |
| Minimālais vēršanas spēks pēc EN 1154 | 2 |
| Series | TS 2000 |
| Vērtņu skaits | 1 vērtne |
