Emergency exit door lock BMH 1013 E

Product code
MB00000654
All prices include VAT
From €36.51
From €36.51
Only %1 left
Reset selection
Would like different processing and/or package?
The selected product is currently out of stock.
Emergency exit door lock BMH 1013 E
Manufacturer - BMH

    • corresponds with DIN 18250, EN 179 and EN 1125 technical requirements for emergency exit doors
    • suitable for use only with certified handle sets
    • correspond with fire safety requirements according to EN 1634-1 and DIN 4102-18
    • suitable for wooden and metal doors with high usage
    • lock function E
    • galvanised, closed lock case
    • PZ keyhole, key-retractable single turn latch
    • split handle hole: 9 mm
    • bolt and latch - galvanised metal
    • bolt projection: 15 mm
    • centre distance: 72 mm
    • standard spindle depth D: 65 mm
    • other options for spindle depth D: 55 / 60 / 65 / 80 / 100 mm
    • connecting screw holes
    • stainless steel face plate
    • lock compatible with divided emergency door handle spindle and matching handles
    • available finishes: stainless steel (face plate)
    •

NB!
The key must always be taken out of the cylinder after locking/unlocking!



All prices include VAT
  • Products
  • Price
  • In Stock
  • Quantity
  1. 1013 E panic door lock PZ55/72/20, left, stainless steel
    1013 E panic door lock PZ55/72/20, left, stainless steel
    Code: SB00013428
    Art. Nr.: 820 1013.000065
    Price:
    From €78.73
    In Stock: 0 pc.
  2. 1013 E panic door lock PZ65/72/24, left, stainless steel
    1013 E panic door lock PZ65/72/24, left, stainless steel
    Code: SB00013430
    Art. Nr.: 820 1013.000087
    Price:
    From €36.51
    In Stock: 13 pc.
  3. 1013 E panic door lock PZ55/72/20, right, stainless steel
    1013 E panic door lock PZ55/72/20, right, stainless steel
    Code: SB00013429
    Art. Nr.: 820 1013.000066
    Price:
    From €78.73
    In Stock: 0 pc.
  4. 1013 E panic door lock PZ65/72/24, right, stainless steel
    1013 E panic door lock PZ65/72/24, right, stainless steel
    Code: SB00013431
    Art. Nr.: 820 1013.000088
    Price:
    From €36.51
    In Stock: 9 pc.
bolt projection 15 mm
bundling options lock compatible with split spindle
centre distance PZ 72 mm
class as per EN 12209 (DIN 18251) class 4 according to DIN 18251 (EN class 3)
compatibility standard German (DIN)
door direction when ordering please indicate door swing direction
evacuation function E
face plate width 20 / 24 mm
face plate finish Nerūsējošais tērauds
face plate length 235 mm
face plate shape rounded
fire safety complies with EN standard fire safety requirements
handle square spindle size 9 mm
installation type mortise
latch key-retractable
latch material galvanised metal
leaf material for wooden and metal doors
load capacity high
lock bolt single turn
lock bolt material galvanised metal
lock case galvanised closed
lock operation mechanical
lock type single-point lock for hinged doors
locking function PZ - with profile cylinder hole
Manufacturer BMH
possible spindle depth 55/60/65/80/100 mm
purpose for interior doors / for exterior doors
sound insulation no
suitable for emergency exits complies with 179 and EN 1125 - emergency/panic door equipment
Kas ir evakuācijas durvju slēgšanas funkcijas?
Evakuācijas un trauksmes durvis, kurās iebūvētas pēc EN 179 vai EN 1125 atbilstošas slēdzenes vai vairākpunktu slēdzenes, evakuācijas virzienā bez atslēgas var atvērt vienmēr - arī - aizslēgtā stāvoklī. Evakuācijas funkcija nosaka evakuācijas durvju ...
