GEZE chain drive ECchain

Product code
MB00000949
All prices include VAT
From €167.08
From €167.08
Only %1 left
Automated ventilation in wooden, PVC and aluminium profiles with adjustable opening width depending on required air flow quantity.
Reset selection
Would like different processing and/or package?
The selected product is currently out of stock.
GEZE chain drive ECchain
Manufacturer - GEZE (Germany)

    • straightforward ventilation automation (230 V) in the window and façade area
    • suitable for universal use, including in apartments and residential houses
    • suitable for inward and outward opening, bottom-hung or top-hung windows
    • may also be used on small fanlights, with maximum opening angle
    • suitable for use in wooden, PVC and aluminium profile systems
    • adjustable opening width available depending on required air flow quantity
    • quick and easy installation onto window frame
    • length with console 409 mm, without console 390 mm
    • height: 44 mm
    • depth: 63 mm
    • minimum space requirements:
    • on frame: 55 mm (inward-opening windows) / 35 mm (outward opening windows)
    • on leaf: 37 mm (inward-opening windows) / 20 mm (outward opening windows)
    • possible stroke length: 200 or 400 mm
    • opening and closing speed: 9 mm/s
    • max tensile and compressive force: 250 N
    • max leaf weight: 130 kg
    • rebate: 10-23 mm
    • supply voltage: 230 V ± 10%
    • current consumption: 0,13 A
    • length of power supply cable: 2 mm, cable dimensions: 4 x 0,75 mm2
    • temperature range: -5 – 60 °C
    • IP/protection rating: IP 30/II
All prices include VAT
  • Products
  • Price
  • In Stock
  • Quantity
  1. Chain drive ECCHAIN with console, white
    Chain drive ECCHAIN with console, white
    Code: SB00004479
    Art. Nr.: 148260
    Price:
    From €167.08
    In Stock: 0 pc.
  2. Chain drive ECCHAIN with console, black
    Chain drive ECCHAIN with console, black
    Code: SB00004477
    Art. Nr.: 148258
    Price:
    From €167.08
    In Stock: 0 pc.
  3. Chain drive ECCHAIN with console, grey
    Chain drive ECCHAIN with console, grey
    Code: SB00004478
    Art. Nr.: 148259
    Price:
    From €167.08
    In Stock: 0 pc.
with heat recovery no
air flow control adjustable opening
electrically operated blower no
electric current 0.13 A
height 44 mm
installation in wooden, plastic and aluminium profile systems
IP rating IP 30/II
leaf maximum weight 130 kg
length 409 mm (with bracket); 390 mm (without bracket)
Manufacturer GEZE
opening and closing speed 9 mm/s
operating mode air intake
operational temperature range from -5 °C to +60 °C
overlap 10 - 23 mm
power cable 4 x 0.75 mm2, length 2 mm
purpose for tilt and turn windows
suitable for bathrooms no
suitable for bedrooms yes
supply voltage 230 V ± 10%
throw 200 / 400 mm
total depth 63 mm
ventilation device type for building into windows
ventilation type passive ventilation
